External Pilot Cage Protection
A robust access barrier solution using hydraulic telescopic bollards, integrated with high-strength galvanized components and remote push-button controls.
Key Highlights
- Hydraulic telescopic bollards offer secure access control for high-risk airfield zones.
- Operable via dual-side control panels with key switch safety mechanisms.
- Manual override and genset support ensure uninterrupted operation during emergencies.
- IP67-rated construction and wide temperature tolerance for all-weather reliability.
- High-load galvanized steel bollards act as physical safety nets against unauthorized vehicle access.
- Option for customization as per user requirements.
Features
- Drive Mechanism: Hydraulic
- Type of Boom: Telescopic / Two-Fence
- Power Supply Type: 3-Phase 440V AC, 50 Hz
- Motor Power Rating: 3.8 KW
- Rising Time: Up to 6 seconds
- Operating Temperature Range: -20°C to +60°C
- Lowering Time: Up to 5 seconds
- Manual Lowering Option: Customized
- Control Panel: Operable from both sides of the bollard via push buttons with key switch control
- Ingress Protection Rating: IP 67
- Illumination: Red LED / Reflective Tape
- Emergency / Power Failure Operation: Manual operation with hand-pump, Operation with Genset
- Total Load Capacity: 60 kN
- Vertical Load Capacity: 100 kN
- Electrical Control Enclosure: Steel or Galvanized Powder-Coated Cabinet
